General introduction

Introduction of construction works of Dung Quat Oil Refinery - Vietnam's first oil refinery

Bể chứa dầu thô - BSR

1.Location and Area of use

Location icon Location:

The factory was built in Dung Quat Economic Zone, located in Binh Thuan and Binh Tri communes, Binh Son district, Quang Ngai province.

 Area of use:

About 956 hectares (including 140 hectares for future expansion) including 485 hectares of land and 471 hectares of sea surface, of which (currently): 110 hectares of the main factory; Crude oil storage area 42 ha; Product storage area 43.83 ha; Crude oil pipeline area, sea water supply and discharge 17 ha; Product pipeline route 77.46 ha; Product export port 135 ha and berthless oil import buoy system, undersea pipeline and ship turning area 336 ha.

Sơ đồ mặt bằng bố trí NMLD Dung Quất
Layout Plan of Dung Quat Oil Refinery

2. Processing capacity and raw materials

Processing capacity: 6.5 million tons of crude oil/year, equivalent to 148,000 barrels/day. After completing the expansion upgrade: 8.5 million tons of crude oil/year, equivalent to 192,000 barrels/day.

Material

  • Stage 1: Processing 100% of Bach Ho - Vietnam crude oil (or equivalent crude oil).

  • Stage 2: Processing sour oil.

3. Technology configuration



4. Operation Process of Oil Refinery

  • Crude oil is imported into the refinery for processing through a single-point mooring buoy system (SPM) capable of receiving ships with a tonnage of 80,000 to 150,000 tons (After upgrading and expanding 300,000 tons) and the oil pipeline from the float to the crude oil storage area is about 4.2 km long.

  • Crude oil is pumped into the crude oil storage area including 08 tanks with equal capacity, each tank is 65,000m3. Then crude oil is pumped into the atmospheric distillation tower with a capacity of 140,000 barrels a day to separate into segments such as: Gas, Naptha, Kerosen, Heavy and light Gas oil and atmospheric residue.

  • Gas is brought to the Gas processing workshop and Propylene is recovered to produce liquefied gas and Propylene is sent to the Polypropylene plant to process plastic beads.

  • Naptha is brought to technology workshops to improve the octane number of gasoline blends.

  • Kerosen is taken to the kerosen processing plant to produce Jet A1 jet fuel and kerosene.

  • Heavy and light gas oil is sent to the processing segments to produce diesel oil.

  • Atmospheric residues are taken to the treatment workshop to produce products: gasoline, diesel, fuel oil...

  • All technology and auxiliary workshops of the Factory are operated at the Central Control House through a modern DCS distributed control system with control, monitoring, recording, storage and display functions. Plant operation data.

  • To serve the operating technology workshops, the refinery has 10 auxiliary workshops such as power plants, workshops supplying compressed air and control gas, chemicals, cooling water, fire-fighting water and domestic water. , fuel gas, fuel oil, wastewater treatment workshop...

  • Products from the technology area are brought to the intermediate storage area, where the products are checked for quality and mixed at a reasonable rate before being sent to the product storage area by long pipes. about 7 km.

  • The products of the factory are stored in 22 tanks of finished products and sold by road and by sea to export all products of the factory.

  • The port for exporting products by sea is located in Dung Quat Bay, about 3 km from the Product Storage Area. The port of exporting products by sea exports products through 6 berths for ships with a tonnage of 1,000 to 30,000 tons.

  • In order to prevent waves, protect the product export port of the refinery and other works in Dung Quat Bay, a breakwater was built with a total length of nearly 1,600m, the dike surface is 11m wide, and the height of the dyke is compared to the surface. sea water from 10 to 11m.

5. Product structure

Products Thousand tons/year
Propylene 136 - 150
Liquified Petroleum Gas (LPG) 400 - 420
RON 92 1.400 – 1.800
RON A95 600 - 700
Jet A1. kerosene/flying fuel 80 - 400
Automotive Diesel Oil 2.900 – 3.200
Fuel Oil (FO) 60 - 100
Polypropylene 135 - 150
Sulfur 1,5 - 2

6. Total investment

  • According to Decision 514/QD-TTg dated 10/7/1997 (self-investment period from 1997 to 1999): Total investment is 1.5 billion USD;

  • According to Decision 560/CP-DK dated June 21, 2001 of the Government (JV phase with Russia): The total investment for the project is USD 1,297 billion excluding financial fees;

  • According to Decision 546/QD-TTg dated June 17, 2005 (Stage to return to self-investment): US$2,501 billion; According to Decision 546/QD-TTg dated June 17, 2005 (Stage back to form). self-investment mode): USD 2,501 billion;

  • According to Decision No. 1291/QD-TTg dated August 17, 2009 (after completing the construction and testing of the factory): Approving the total investment of 3.053 billion USD.

Introduction of project items

Xuất bản thông tin

<div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="Vận hành nhập dầu thô tại SPM của NMLD Dung Quất" height="666" src="/documents/37629/38824/hmct-1-1.png/87c58672-65bb-d7c1-cf9c-5abaf20efb40?t=1735974095496" width="1000" /> <figcaption>Operating crude oil import at SPM of Dung Quat refinery</figcaption> </figure> </div> <ul> <li>Float diameter: 12m.</li> <li>Float height: 5m (submerged part is 3.75m, floating part is 1.25m).</li> <li>Capacity of the float: Designed to import crude oil with a capacity of 6,000 m3/h.</li> <li>Capacity of shuttle cleaning system (pig): 1300 m3/h.</li> </ul> <p>Crude oil is pumped from the tanker through the SPM buoy, distribution pipe system (PLEM), the crude oil pipeline to the crude oil storage area. The SPM buoy can dock ships with a tonnage of 150,000 tons. The crude oil pipeline from the SPM buoy to the crude oil storage area is about 4.2 km long, of which there is 3.2 km underground passage on the seabed and about 1 km underground passage on the shore.</p> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="Phao SPM nơi nhập dầu thô của NMLD Dung Quất tại vịnh Việt Thanh" height="666" src="/documents/37629/38824/hmct-1-2.png/67ccab34-2f28-8996-9f47-53e6b5abe292?t=1735974096345" width="1000" /> <figcaption>SPM buoy where the crude oil of Dung Quat refinery is imported in Viet Thanh Bay</figcaption> </figure> </div>
<p>&nbsp;&nbsp;</p> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="" src="https://bsr.com.vn/BTEC/images/1711105108743/6362768888601537965.jpg" /> <figcaption>Construction and installation of crude oil tanks​</figcaption> </figure> </div> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="" src="https://bsr.com.vn/BTEC/images/1711105108743/6362768901455073146.jpg" /> <figcaption>NMLD Dung Quat crude oil tank area</figcaption> </figure> </div> <p>Total number of crude oil tanks: 08 tanks</p> <ul> <li>Total construction and installation capacity: 760,133 m3</li> <li>Total working capacity: 520,000 m3</li> </ul> <p>The crude oil tanks have equal capacity, diameter 69.0 m, height 22.4 m. The tanks are designed with floating roofs, and are made of carbon steel. In the crude oil tank area, there are also rack systems, pipeline supports, transformer stations, oil pumping stations, wastewater collection systems, water supply and drainage systems, power supply systems for pumping stations and protection power, and other auxiliary works.</p> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="" src="https://bsr.com.vn/BTEC/images/1711105108743/6362768904488546647.jpg" /> <figcaption>NMLD Dung Quat crude oil tank area</figcaption> </figure> </div>
<p><strong>Technology workshops (including 14 workshops):</strong></p> <ul> <li><strong>Atmospheric pressure crude oil distillation workshop (CDU)</strong></li> <li><strong>Naphtha hydrotreating workshop (NHT)</strong></li> <li><strong>Continuous catalytic reforming workshop (CCR)</strong></li> <li><strong>Residual catalytic cracking workshop (RFCC)</strong></li> <li><strong>Propylene recovery workshop (PRU)</strong></li> <li><strong>Amine regeneration workshop (ARU)</strong></li> <li><strong>LPG treatment workshop (LTU)</strong></li> <li><strong>Sour water treatment workshop (SWS)</strong></li> <li><strong>Alkali neutralization workshop (CNU)</strong></li> <li><strong>Kerosene treatment workshop (KTU)</strong></li> <li><strong>Sulfur recovery workshop (SRU)</strong></li> <li><strong>RFCC Naphtha treatment workshop (NTU)</strong></li> <li><strong>Light Naphtha isomerization workshop (IZOMER)</strong></li> <li><strong>LCO hydrotreating workshop (LCO-HTD)</strong></li> </ul> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="" src="https://bsr.com.vn/BTEC/images/1711105279254/6362768906276248898.jpg" /> <figcaption>Construction site of technology workshops in March 2007</figcaption> </figure> </div> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="6362768908312165349.jpg" src="https://bsr.com.vn/BTEC/images/1711105279254/6362768908312165349.jpg" /> <figcaption>Import of equipment High main separation tower Heavy main separation tower T-1501 528 tons, 68.28m high, 8.99m diameter.</figcaption> </figure> </div> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="" src="https://bsr.com.vn/BTEC/images/1711105279254/63627689107299036310.jpg" /> <figcaption>Transporting Propane/Propylene Separation Tower T-2103, 81.3m high, 460 tons in weight, 9.15m widest diameter.</figcaption> </figure> </div> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="" src="https://bsr.com.vn/BTEC/images/1711105279254/63627689124876041611.jpg" /> <figcaption>Construction and installation of Crude Oil Distillation Tower T-1101, 6.7m in diameter, 41.84m high, 319 tons in weight.</figcaption> </figure> </div> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="" src="https://bsr.com.vn/BTEC/images/1711105279254/63627689188363672912.jpg" /> <figcaption>Construction and installation of Clean Catalyst Hopper D-1505 at RFCC workshop.</figcaption> </figure> </div> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="" src="https://bsr.com.vn/BTEC/images/1711105279254/63627689209018854313.jpg" /> <figcaption><em>Construction and installation of Dung Quat Refinery's technological pipeline</em></figcaption> </figure> </div> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="63627689362092609614.jpg" src="https://bsr.com.vn/BTEC/images/1711105279254/63627689362092609614.jpg" /> <figcaption>Construction site of technological workshops, July 2008</figcaption> </figure> </div> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="" src="https://bsr.com.vn/BTEC/images/1711105279254/63627689381308708715.jpg" /> <figcaption>Technological workshops of Dung Quat Refinery</figcaption> </figure> </div> <p>All technological and auxiliary workshops of the Plant are operated at the Central Control House through a modern DCS distributed control system with the functions of controlling, monitoring, recording, storing and displaying data on the Plant's operational process.</p> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="" src="https://bsr.com.vn/BTEC/images/1711105279254/63627689401651872316%20(1).jpg" /> <figcaption>A corner of Dung Quat Refinery's Control Center (CCC)</figcaption> </figure> </div> <p>To serve the operation of the technological workshops, the Plant has 10 auxiliary workshops such as the Power Plant, workshops supplying compressed air and control air, chemicals, cooling water, fire fighting water and domestic water, fuel gas, fuel oil, wastewater treatment workshop, etc. to ensure the operation of the technological workshops and other related items.</p>
<p>The system includes an offshore seawater intake, a seawater tank, seawater pipes, seawater pumps, hypochlorite charging units and seawater discharge heads. The system is designed to: Provide seawater for cooling the Condenser Turbines of the RFCC workshop and the Power Plant, and provide seawater for cooling the cooling water workshop.</p> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="" src="https://bsr.com.vn/BTEC/images/1711105838243/63627689441443148218.jpg" /> <figcaption>Construction of the seawater cooling system</figcaption> </figure> </div> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="63627689461675305419.jpg" src="https://bsr.com.vn/BTEC/images/1711105838243/63627689461675305419.jpg" /> <figcaption>Construction and installation of the seawater cooling pipeline</figcaption> </figure> </div>
<ul> <li>Total number of intermediate tanks: 23 tanks</li> <li>Total construction capacity: 336,727 m3</li> </ul> <p>The intermediate tank area is used to store intermediate products and products after mixing (test tank) before pumping to the product tank area.</p> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="" src="https://bsr.com.vn/BTEC/images/1711105878019/63627689482532498420.jpg" /> <figcaption>Intermediate tank area</figcaption> </figure> </div>
<p>The power plant has 4 units with a total capacity of 108 MW and 4 boilers with a total capacity of 784 tons of steam/h at a temperature of 505oC and 107 atmospheres. The power plant is the source of steam and electricity used in the Refinery.</p> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="" src="https://bsr.com.vn/BTEC/images/1711105707147/63627689421321997417.jpg" /> <figcaption>Power Plant</figcaption> </figure> </div>
<p>Pipeline system from the factory to the tank area: Length is about 7 km, including 12 pipelines (8 product pipelines, 4 auxiliary pipelines/residue oil), with sizes from 5.08 cm - 40.64 cm, to transport products such as RON 92/95 gasoline, Jet A1, Diesel oil, FO, Propylene, LPG, industrial water, boiler water, nitrogen and waste oil.</p> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="" src="https://bsr.com.vn/BTEC/images/1711105909848/63627689502687651221.jpg" /> <figcaption>Finishing paint for product pipeline system</figcaption> </figure> </div> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="" src="https://bsr.com.vn/BTEC/images/1711105909848/63627689543996013922.jpg" /> <figcaption>Dung Quat NMLD product pipeline system</figcaption> </figure> </div> <p>Pipeline system from product storage tank area to product export area by sea: Length is about 3 km, with 15 pipelines (10 product pipelines, 5 auxiliary pipelines/waste oil/ballast water), size from 5.08 cm - 76.2 cm to transport products such as Mogas 90 gasoline, Mogas 92/95 gasoline, Jet A1, Auto diesel, FO, Propylene, LPG, fire water, ballast water, domestic water, control gas and nitrogen.</p>
<ul> <li>Total number of product tanks: 22 tanks</li> <li>Total working capacity: 393,073 m3</li> </ul> <p>The product tank area is divided into 8 plots of land, each plot has 2-5 tanks, the plots are separated by earthen dams, the dam roof is reinforced with reinforced concrete. The product tank area also has items such as transformer stations, fire stations, water supply and drainage systems, power supply systems, air conditioning and ventilation, wastewater treatment plants and other auxiliary works.</p> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="" src="https://bsr.com.vn/BTEC/images/1711105962200/63627689566952326923.jpg" /> <figcaption>Construction and installation of liquefied petroleum gas (LPG) toilets</figcaption> </figure> </div> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="" src="https://bsr.com.vn/BTEC/images/1711105962200/63627689603156397724.jpg" /> <figcaption>Liquefied petroleum gas (LPG) toilets Product tank area</figcaption> </figure> </div> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="" src="https://bsr.com.vn/BTEC/images/1711105962200/63627689628309836425.jpg" /> <figcaption>Dung Quat NMLD product tank area</figcaption> </figure> </div>
<p>&nbsp;&nbsp;</p> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="" src="https://bsr.com.vn/BTEC/images/1711106199689/63627689940605698736.jpg" /> <figcaption>Mechanical maintenance workshop area</figcaption> </figure> </div> <p>The administrative and operational building is located north of the main factory area, with a total area of ​​about 10 hectares, on a level ground elevation of +11m, planned in an area with no risk of fire or explosion. Including administrative buildings, security houses, medical stations, fire stations, auto repair garages, canteens, shops, laundry rooms, mechanical maintenance workshops, electrical maintenance workshops, communication systems, maintenance warehouses, roads, yards, trees, flower gardens and technical systems connecting to the main factory area.</p>
<p>The PP factory has a capacity of 150,000 tons/year of homopolymer plastic products based on 8,000 operating hours per year, built on the copyrighted Hypol-II technology of Mitsui Chemical Corporation, Japan.</p> <p>The input material is propylene, which is one of the products of the Oil Refinery. From propylene, together with hydrogen and catalysts, the factory produces over 30 types of PP homopolymer plastic products for different applications such as injection molding, blow molding, film, and fiber, meeting part of the domestic market's demand for PP plastic.</p> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="" src="https://bsr.com.vn/BTEC/images/1711106233412/63627689957064640137.jpg" /> <figcaption>Polypropylene plastic granule packaging line</figcaption> </figure> </div> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="" src="https://bsr.com.vn/BTEC/images/1711106233412/63627689974525638838.jpg" /> <figcaption>Inauguration and installation of the Polypropylene Factory signboard</figcaption> </figure> </div> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="" src="https://bsr.com.vn/BTEC/images/1711106233412/63627689994130760139.jpg" /> <figcaption>Panorama of the Polyproptlene Factory</figcaption> </figure> </div>
<p>The tank truck loading station is located on the west side of the product storage tank area, used to load popular products such as Mogas 92/95, Mogas 90, Jet A1, Auto Diesel and FO.</p> <p>The loading station is designed with 2 loading racks, each rack is equipped with loading booms that can serve both sides of the loading rack, the station can load 4 trucks at the same time. The pumping station is also designed with a reserve area for future expansion.</p> <div style="text-align:center"> <figure class="image" style="display:inline-block"><img alt="" src="https://bsr.com.vn/BTEC/images/1711106020601/63627689648127969927.jpg" /> <figcaption>Product loading station by road</figcaption> </figure> </div>
